DRY GRANULATOR

1. FUNCTION AND SPECIFICATION
1-1 FUNCTION：DRY GRANULATOR IS DESIGNED TO PROCESS BIGGER AND IRREGULAR GRANULES INTO UNIFORM SIZES OF GRANULES AFTER THE DRYING PROCESS.
1-2 SCREEN：THERE ARE THREE KINDS OF SIZE SCREEN FOR THIS MACHINE LIKE,＃12、＃20、
＃30. AND ALL OF THE SCREEN MATERIAL IS SUS316.

2. THEORY
THE PRINCIPLE OF THE DRY GRANULATOR IS TO APPLY TWO CONTINUOUSLY TURNING ROLLERS WHICH PRESS OUT EVEN SIZES OF DRY GRANULES THROUGH A WIDE SCREEN.
